Standard
Nominal size
9 mm
Mounting position
optional
Design
Straight design
Size of pack
10
Design
Push-pull principle
Operating pressure complete temperature range
-0.095 MPa ... 0.6 MPa
Operating pressure complete temperature range
-0.95 bar ... 6 bar
Operating pressure complete temperature range
-13.775 psi ... 87 psi
Temperature-dependent operating pressure
-0.095 MPa ... 1.4 MPa
Temperature-dependent operating pressure
-0.95 bar ... 14 bar
Temperature-dependent operating pressure
-13.775 psi ... 203 psi
Note on operating pressure
Water: max. 0.6 MPa at max. 50°C
Operating medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Water (liquid, ice-free)
Note on operating and pilot medium
Lubricated operation possible
Corrosion resistance class CRC
1 - Low corrosion stress
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Cleanroom class
Class 4 according to ISO 14644-1
Ambient temperature
-10 °C ... 80 °C
Product weight
16 g
Pneumatic connection, port 1
For tubing outer diameter of 10 mm
Pneumatic connection, port 2
For tubing outside diameter of 10 mm
Colour of release ring
Blue
Note on materials
RoHS-compliant
Material housing
PBT
Material release ring
POM
Material tubing seal
NBR
Material tubing clamp component
High-alloy stainless steel
